LLDPE & HDPE Liner

LINEAR-LOW DENSITY POACETHYLENE (LLDPE)

LLDPE is a very flexible linear-low density polyethylene geomembrane. Provides exceptional elongation, tensile, and impact strength. Delivers excellent protection from UV rays and harsh weather conditions.

Preferred for ease-of-field seaming or factory fabricated custom size panels to save install time. Custom panels are accordion rolled onto 7’ core. 15-year UV exposed warranty.

Rolls available in 10’ Width increments and 5’ Length increments.



LLDPE	WT (lb)
LLDPE WT (lb) 20 mil panels (Up to 75,000 sq ft)	0.10 lb per ft2
30 mil panels (Up to 50,000 sq ft)	0.15 lb per ft2
40 mil panels (Up to 37,500 sq ft)	0.20 lb per ft2

HIGH-DENSITY POLYETHYLENE LINERS (HDPE)

HDPE (High-Density Polyethylene) geomembrane is a rigid liner that offers exceptional durability, chemical resistance, and low permeability for long-term performance. It’s a cost-effective choice for large or exposed lining projects, providing excellent protection against UV rays and harsh weather conditions.

Field seaming requires specialized welding equipment and certified technicians. Includes a 15-year UV-exposed warranty.

Available only in master rolls of 23' width increments (no prefabricated sizes available).

HDPE	WT (lb)
40 mil rolls (Up to 800' length)	0.20 lb per ft2
60 mil rolls (Up to 600' length)	0.30 lb per ft2

Make sure to add Underlayment to your liner installation to stabilize your soil and protect your liner.

Need a Quote for Your LLDPE and HDPE Project?

Interested in a LLDPE or HDPE custom sized liner? Use this form to recieve a quote.

Large liners can be fabricated in increments of 12.5 feet up to 250' x 250' for 20 mil and 250' x 150' for 30 mil.

Contact us at 1-800-553-5605 or submit the form below to get a quote on your project.
